Forsdal Sound Protection

Peace and quiet is life quality and it increases the property value of your home. Our solid wood sound protection fencing not only looks great but also significantly lowers the noise level of nearby streets, railways and not so quiet neighbours. Forsdal meets the requirements for structural noise barriers on roads (tested in accordance with DIN EN ISO 1793-1 and ZTV-Lsw 06), and our sound-absorbing variant also meets the sound insulation requirements for railroad lines (Rili 804.5501 2013).

  • Variation A: With 45 mm planks, sound reflexion of 25 dB (sound protection group B3)
  • Variation B: With the one-sided highly absorbent noise protection wall made of 28 mm planks and absorber elements, a sound reflection of 27 dB and sound absorption of 10 dB (sound insulation group A3/ highly absorbent) is achieved. This qualifies this variant especially for densely built-up areas.

Find a dealer in your area

Osmo privacy fencing Forsdal in untreated Larch
Osmo privacy fencing Forsdal reduces noise from streets and roads
Osmo privacy fencing Forsdal as assembly kit
Osmo privacy fencing Forsdal - Made in Germany
Osmo privacy fencing Forsdal in untreated Larch
Osmo privacy fencing Forsdal reduces noise from streets and roads
Osmo privacy fencing Forsdal as assembly kit
Osmo privacy fencing Forsdal - Made in Germany

OUR VARIATIONS FOR FORSDAL SOUND PROTECTION

VARIATION A: Reflecting sound protection

The sound is reflected by the 45 mm thick planks.

Osmo privacy fencing Forsdal variation A with reflecting sound protection
VARIATION B: Absorbing sound protection

To protect those living opposite you from reflected noise, Osmo also offers a sound absorbing variation. 28 mm thick planks are combined with absorbing elements to reduce noise pollution by approx. 29.5 dB. For example, the noise of a truck at approx. 90 dB is reduced down to a comfortable noise level of 60 dB.

Osmo privacy fencing Forsdal variation B with absorbing sound protection

SELECT A WOOD SPECIES AND THE ELEMENTS

Pine pressure impregnated Green

Thanks to the pressure impregnation, the wood is resistant to fungal and mould attack.

Wood species for Osmo privacy screens - Pine pressure impregnated Green
Pine pressure impregnated Grey

Creates a seamless transition to natural grey. Thanks to the pressure impregnation, the wood is resistant to fungal and mould attack.

Wood species for Osmo privacy screens - Pine pressure impregnated Grey
Larch untreated

Wood species with lively wood grain. The resin protects the wood like a natural impregnation. Also available pre-treated with UV protection.

Wood species for Osmo privacy screens - Larch untreated

Our elements

Forsdal Variation A slat 45 mm
  • Covering width 135 mm
  • 205 x 4.5 x 14.6cm
  • Pine pressure impregnated green or grey, Larch untreated or with UV protection
Osmo sound protection Forsdal Variation A slat 45 mm
Forsdal Variation A end profile
  • for 28 mm und 45 mm slats
  • 200 x 4.5 x 7 cm
  • Pine pressure impregnated green or grey, Larch untreated or with UV protection
Osmo sound protection Forsdal Variation A end profile
Forsdal gate (reflecting sound protection)
  • 98 x 4,5 x 205 cm
  • incl. hardware
  • Pine pressure impregnated green or grey or Larch untreated
Osmo Forsdal gate reflecting sound protection
Forsdal Variation B slat 28 mm
  • Covering width 135 mm
  • 205 x 2.8 x 14.5 cm
  • Pine pressure impregnated green or grey, Larch untreated or with UV protection
Osmo sound protection Forsdal Variation B slat 28 mm
Forsdal Variation B end profile
  • for 28 mm slats with absorption element
  • 200 x 4.5 x 14.1 cm
  • Pine pressure impregnated green or grey, Larch untreated or with UV protection
Osmo sound protection Forsdal Variation B end profile
Forsdal Variation B absorption element
  • for 28 mm slats
  • 199 x 8 x 72 cm
  • Pine pressure impregnated green or grey or Larch untreated
Osmo sound protection Forsdal Variation B absorption element

Posts for anchor installation
  • Dimension: 10 x 14 x 220 cm
  • Finger-jointed and laminated posts
  • Pine pressure impregnated Green or Pine factory-finished
Forsdal Sound Protection
Posts for in-ground installation
  • Dimensions: 10 x 14 x 300 cm
  • Finger-jointed and laminated posts
  • Pine pressure impregnated Green or Pine factory-finished
Forsdal Sound Protection
Corner posts for anchor installation
  • Dimensions: 10 x 14 x 220 cm
  • Finger-jointed and laminated posts
  • Pine pressure impregnated Green or Pine factory-finished
Forsdal Sound Protection
Corner posts for in-ground installation
  • Dimensions: 10 x 14 x 300 cm
  • Finger-jointed and laminated posts
  • Pine pressure impregnated Green or Pine factory-finished
Forsdal Sound Protection
Post cap
  • Dimensions: 12,5 x 15 x 4,2 cm
  • Finger-jointed and laminated posts
  • Pine pressure impregnated Green or Pine factory-finished
Forsdal Sound Protection

Technical information and installation

Installation instructions (German) PDF, 729 KB Common wood features (German) PDF, 371 KB Assembly instructions single gate wood (German) PDF, 129 KB
